Style:
|
SSD
|
SSD Capacity:
|
64GB
|
Material:
|
Metal
|
Size:
|
100*70*7mm
|
Color:
|
Black
|
Warranty:
|
3 Years
|
Flash Type:
|
2D MLC
|
Certificate:
|
CE. FCC, Rohs
|
High Speed S1 64GB SSD Laptop 2.5 Inch SATA Solid State Drive MLC Black For PC
S1 64G
Model
|
SATA 2.5 MLC
|
General
|
Form factor
|
2.5
|
Interface
|
SATA 3
|
Performance
|
Capacity
|
64GB
|
Sustained Read
|
420MB/S
|
Sustained Write
|
80MB/S
|
Random IOPS
|
|
Storage Media
|
NAND Flash
|
2D MLC Flash
|
Power Consumption
|
input Voltage
|
5.0V+/_5%
|
Idle
|
0.36W
|
Active
|
1.24W
|
Reliability& Endurance
|
Write endurance
|
8years 100GBytes write and erase per day at 32GB
|
Read endurance
|
unlimited
|
Wear-Leveling Algorithm
|
Dynamic and static wear-leveling
|
Data Retention
|
10years at 25
|
MTBF
|
1,000,000hours
|
ECC
|
Supports BCH ECC 8bits or 15bits in 512 bytes
|
Bad Block Management
|
Auto Bad Block Management in system
|
Environment
|
Operating Temperature
|
0~70
|
Non-operating Temperature
|
-40~85
|
Shock
|
2,000G(0.3ms half sine wave)
|
Vibration
|
20G(40-2000HZ)
|
Ambient Humidity
|
5-95%
|
Warranty
|
2years
|
Available unit
|
Available
|
NO EOL
|
Testing Platform
|
CPU: Athlon 64×2 5200+ 2.7GHz,SDRAM:DDR2 800(PC6400) 2048 MB×1PCS, Mainboard: RS780 (ATI Radeon HD 3200 Graphics)System:Professional SP2
|
Testing Software
|
HDBench3.4.0.3, IOMeter 2006.07.27
|
Physical Dimensions & Weight
|
Height(mm)
|
7+/_0.25
|
Width(mm)
|
69.8+/_0.25
|
Length(mm)
|
100.2+/_0.25
|
Weight(g)
|
70±5
|
Q: What does the 2 Channels 4 Channels 8 Channels 10 Channels mean?
A:It means the qty of chips of read and write data at same time. 2 channels means 2 chips do reading and writing.10-channels means 10 chips in reading and writing at the same time, depending on the management capabilities of the controlling IC. The control IC chip of INTEL 10-channel can manage 10 chips read and write data simultaneously , which can greatly enhance the speed of reading and writing data to increase work efficiency . This is not a strict interpretation, just to assist those who do not understand the SSD works to understand the concept of the channel.
Q: Will the SSD performance degradate after a period of time ?
A: In the earlier time. SSD donnot have TRIM function. its performance will degrade after using for some time, the garbage-collected function in TRIM can sort out the affective data and delete the useless data to get more space. this is good for data reading to ensure SSD in relatively good condition. you can try to use HDD Erase to restore the original performance. but we would suggest you not use too often as it will have some degree defect on the flash chips.
